This machine is mainly applied in covering and folding various notebooks, photo books (photo album), folders, certificates, hardcover books. This process is finished easily at twice on both sides at the same time by one operator. It is the good equipment of hard cover post-press binding.
SPECIFICATIONS | ||||||
Model | MF-SCM500A | |||||
Power Supply | 380V/220V, 50HZ | |||||
Mainframe Power | 5.2kw | |||||
Work Speed | 1-3PCS/minute | |||||
Paperboard Thickness | 1-4mm | |||||
Hard Case Spine Width(Min) | 9mm | |||||
Open Book Case Size(Max) | 780x430mm | |||||
Open Book Case Size(Min) | 140x140mm | |||||
Paper Thickness | 80-200g | |||||
Machine Dimensions(L×W×H) | 1780×1620×1400mm | |||||
Packaging Size(LxWxH) | 2100*1300*1830mm | |||||
Machine Weight | N.W 550KG; G.W.700KG | |||||
●Automatic paper feeding system; Pneumatic auto foot switch
●Adopting PLC operating system
●Use hot glue (animal glue / Jelly glue)
●Replace products, fast adjustment speed. The thickness of the cardboard could adjusted automatically
●Adjust the size by rotating the handle wheel
●Light Tube inside the working table makes the position more accurate.
Fully Auto Case In Machine
Pressing&Creasing Machine(Enhanced version)
Hard Cover Book Case In Machine
1.Is your company a factory or trading company?
Our company is a factory.
2.What about the samples?
You can visit our factory if you'd like.
3. How to install the machine?
After-sales Service Provided:Online support
After-sales Service Provided:Free spare parts
After-sales Service Provided:Field installation, commissioning and training
After-sales Service Provided:Field maintenance and repair service
After-sales Service Provided:Video technical support
4. What if the machie can't work?
We are avalible 24 hours online.
5. How long is the warranty period?
One year.
6.What are certificates of machine we have?
Our machines all have CE certificates and Certificates of origin.
